| Model | GHWSHS-3.6DA1 | GHWSHS-5.5DA1 | GHWSHS-10.5DA1 | GHWSHS-14DA1 |
| Power Supply | 220~240V/1ph/50Hz |
| Heating Capacity(W) | 3750 | 5300 | 10600 | 14000 |
| Rated Hot Water Production(L/h) | 80 | 114 | 228 | 300 |
| Rated Power Input(W) | 882 | 1232 | 2524 | 3325 |
| Rated Current Input(A) | 4.05 | 5.66 | 11.59 | 14.60 |
Coefficient of Performance (20/15℃, 15℃ in, 25℃ out) | 4.25 | 4.30 | 4.20 | 4.21 |
| Electric Heater | Rated Power Input(W) | 2000 | 4000 |
| Rated Current Input(A) | 9.08 | 9.10 | 18.25 | 18.15 |
| Max. Power Input(W) | 1450 | 1920 | 4400 | 4650 |
| Max. Current Input(A) | 7.22 | 10.50 | 24.05 | 26.85 |
| Refrigerant | R410A |
| Operation Pressure(Low Side)(MPa) | 0.8 |
| Operation Pressure(High Side)(MPa) | 4.2 |
| Max. Allowable Pressure(MPa) | 4.4 |
| Water Tank Volume(L) | 200~300 | 300~500 | 500 |
| Rated Working Pressure of Tank(MPa) | 0.8 |
Compressor
| Rotary |
| Condenser | Shell and tube heat exchanger |
| Fan Motor | Axial flow |
| Electronic Expansion Valve | DunAn 1.3C | EunAn 1.65C | DunAn 2.0C | DunAn 2.5C |
| Electrical Shockproof | Ⅰ |
| IP Class | IPX4 |
| Max. Water Temp. (℃) | 55.0 |
| Operating Ambient Temp.(℃) | -15~46 |
| Noise(dB(A)) | 54 | 55 |
Water Piping Connections(inch)
| G1/2 | G3/4 |
| Net Weight/Gross Weight(kg) | 50/55 | 57/62 | 65/90 | 70/95 |
| Unit Dimensioin(L*D*H)(mm) | 947*370*565 | 1078*390*705 |
| Packed Dimensions(L*D*H)(mm) | 1002*414*591 | 1103*436*850 |
Heating Capacity at Air 20℃/15℃, Water 15℃~55℃
|
| Note: The data above is for reference only. Please refer to the nameplate on the unit if for more specific data. |
