| Model | 7kW | 9kW | 12kW | 15kW | 18kW | 25kW | 35kW | 25kW | 35kW |
| GSPVSHP-7BA1 | GSPVSHP-9BA1 | GSPVSHP-12BA1 | GSPVSHP-15BA1 | GSPVSHP-18BA1 | GSPVSHP-25BA1 | GSPVSHP-35BA1 | GSPVTHP-25BA1 | GSPVTHP-35BA1 |
| AC Power Supply | 220~240V/1ph/50Hz | 380~415V/3ph/50Hz |
| PV Max. Input Current(A) | 18 | 30 | 18 |
| Optimal PV Input Voltage(V) | 100~190 | 190~370 | 180~350 | 360~500 |
| Recommended PV Module Qty. (630W/50.2V)(pcs) | 3 | 3 | 4 | 5 | 6 | 2 strings * 4 modules | 2 strings * 6 modules | 10 | 11 |
| Heating Capacity at Air 26℃, Humidity 80%, Water 26℃ in, 28℃ out |
Heating Capacity(kW)
| 1.70~7.60 | 2.30~9.50 | 3.00~12.00 | 3.80~15.00 | 4.80~18.00 | 6.80~25.00 | 8.80~35.00 | 6.80~25.00 | 8.80~35.00 |
| Power Input(kW) | 0.11~1.12 | 0.15~1.40 | 0.19~1.91 | 0.24~2.50 | 0.30~3.09 | 0.43~4.12 | 0.56~5.15 | 0.43~4.12 | 0.56~5.15 |
| Coefficient of Performance | 6.80~12.80 | 6.80~12.80 | 6.80~13.00 | 6.80~12.80 | 6.80~12.80 | 6.80~12.80 | 6.80~12.80 | 6.80~12.80 | 6.80~12.80 |
| Heating Capacity at Air 15℃, Humidity 70%, Water 26℃ in, 28℃ out |
| Heating Capacity(kW) | 1.40~6.10 | 1.90~7.60 | 2.30~9.80 | 3.00~12.50 | 3.80~16.50 | 5.50~22.00 | 6.40~25.50 | 5.50~22.00 | 6.40~25.50 |
| Power Input(kW) | 0.18~1.24 | 0.25~1.55 | 0.30~1.96 | 0.39~2.76 | 0.50~3.37 | 0.72~4.70 | 0.84~5.20 | 0.72~4.70 | 0.84~5.20 |
| Coefficient of Performance | 4.90~7.60 | 4.90~7.60 | 5.00~7.60 | 4.90~7.60 | 4.90~7.60 | 4.90~7.60 | 4.90~7.60 | 4.90~7.60 | 4.90~7.60 |
Cooling Capacity at Air 35℃, Water 29℃ in, 27℃ out
|
| Cooling Capacity(kW) | 1.00~4.20 | 1.30~5.30 | 1.70~7.20 | 2.10~9.40 | 2.70~11.60 | 3.80~14.90 | 4.90~19.30 | 3.80~14.90 | 4.90~19.30 |
| Power Input(kW) | 0.15~1.11 | 0.19~1.40 | 0.25~1.89 | 0.31~2.47 | 0.40~3.05 | 0.77~3.92 | 0.73~5.08 | 0.77~3.92 | 0.99~5.08 |
| EER | 3.50~6.20 | 3.40~6.00 | 3.60~6.50 | 3.50~6.50 | 3.60~6.50 | 3.80~6.70 | 3.50~6.40 | 3.80~6.70 | 3.50~6.40 |
| General Data |
| Max. Power Input(kW) | 1.55 | 1.78 | 2.55 | 3.15 | 3.75 | 5.17 | 7.25 | 6.43 | 7.25 |
| Max Durrent(A) | 7.3 | 8.3 | 11.8 | 14.5 | 17.5 | 24.5 | 33.5 | 7.9 | 12.8 |
| Water Flow Volume(m3/h) | 2.5 | 3.5 | 4.5 | 5.5 | 6.5 | 9.0 | 12.0 | 9.0 | 12.0 |
Refrigerant
| R32 |
| Heat Exchanger | Titanium |
| Air Flow Direction | Horizontal |
| Kind of Defrosting | By 4-way Valve |
| Compressor | Mitsubishi |
| Casing | ABS |
| Water Proof Level | IPX4 |
Working Temp. Range(℃)
| -15~43 |
| Water Pipe Connection Size | DN50 |
| Noise Level at 1m Distance(dB(A)) | 39~49 | 40~52 | 42~53 | 43~55 | 45~56 | 47~58 | 49~59 | 47~58 | 49~59 |
Noise Level at 10m Distance(dB(A))
| 20~29 | 20~32 | 22~33 | 23~35 | 25~36 | 27~38 | 29~39 | 27~38 | 29~39 |
| Net Weight(kg) | 42 | 43 | 43 | 46 | 50 | 69 | 80 | 70 | 81 |
| Gross Weight(kg) | 53 | 54 | 57 | 59 | 64 | 85 | 96 | 86 | 97 |
| Net Dimensions(mm) | 880*340*590 | 920*380*650 | 1092*445*742 |
| Packed Dimensions(mm) | 930*400*640 | 990*400*761 | 1150*460*870 |
| Note: The data above is for reference only. Please refer to the nameplate on the unit if for more specific data. |
