| Model | GHWVSVP-200AA1 | GHWVSVP-300AA1 |
| Power Supply | 220~240V/1ph/50~60Hz |
| PV Max. Input Current(A) | 18 |
| Optimal PV Input Voltage Range(V) | 100~190 |
| Recommended PV Module Qty. (530W/50.2V) | 3 |
| Energy Class | A+
|
| Heating Capacity at Air 7℃/6℃, Water 15℃ in, 55℃ out |
Heating Capacity(kW)
| 3 |
| Heating Time(H) | 6.25 | 8.35 |
| COP | 3.55 | 3.85 |
| Electric Heater(kW) | 1.6 |
| Noise(dB(A)) | 50 |
Max. Water Outlet Temp.(℃) (without using backup heater) | 70 |
| Max. Water Outlet Temp. | 75 |
| Operation Range(℃) | -7~43 |
| Rated Power(W) | 900+1600(e-heater) |
| Rated Current(A) | 3.9+7.1(e-heater) |
| Rater Water Yield(L/H) | 34.4 |
Air Flow(m3/h)
| 450 |
| Unit Protection | IPX1 |
| Noise(dB(A)) | 43 |
Water Pipe Diameter(inch)
| G3/4 |
| Net Weight(kg) | 67 | 81 |
| Gross Weight(kg) | 82 | 101 |
| Net Dimensions(L*W*H)(mm) | ∅570*1720 | ∅650*1826 |
| Packed Dimensions(L*W*H)(mm) | 640*640*1850 | 720*720*1956 |
| Note: The data above is for reference only. Please refer to the nameplate on the unit if for more specific data. |
