Combining air to water heat pumps with underfloor heating (UFH) has become one of the most efficient and sustainable heating solutions for modern homes. These two technologies are not only compatible but synergistic—delivering exceptional comfort, energy savings, and reduced carbon emissions.
In this article, we’ll explain how air to water heat pumps work with underfloor heating, the benefits of this pairing, and key considerations for design, installation, and performance.
Air to water heat pumps extract ambient heat from the outside air and transfer it into your home’s hydronic heating system. Since they operate most efficiently at lower flow temperatures (typically 30°C–50°C), they are a perfect match for underfloor heating, which is designed to run at similar low temperatures.
This compatibility allows:
Maximum energy efficiency
Stable, even heat distribution
Lower running costs
Greater system longevity
Here’s how the integration functions:
Heat Source: The air to water heat pump extracts low-grade heat from the air.
Heat Transfer: It transfers this energy to water through a refrigeration cycle.
Water Circulation: The heated water circulates through a network of underfloor pipes embedded in screed or beneath the floor surface.
Radiant Heating: The floor gently radiates heat upward, maintaining a consistent room temperature.
Because UFH covers a large surface area, it doesn’t need high water temperatures to heat a room effectively—making it ideal for heat pump performance optimization.
The larger surface area of UFH means lower operating temperatures are sufficient. This enables the heat pump to run at a higher Coefficient of Performance (COP), maximizing savings.
Underfloor heating provides even, radiant warmth without drafts or cold spots—unlike traditional radiators.
Both air to water heat pumps and UFH systems operate quietly, contributing to a more peaceful living environment.
Using renewable heat from the air drastically reduces CO₂ emissions compared to gas or oil boilers.
This eco-friendly pairing complies with future building regulations and qualifies for renewable energy incentives in many regions.
To ensure peak performance and long-term reliability, consider the following:
High levels of floor and building insulation are critical. Poor insulation can negate efficiency gains.
Design the system for flow temperatures around 35–45°C. Higher temperatures reduce heat pump efficiency.
Screed floors retain heat longer and are ideal for heat distribution.
Timber floors can work but may require closer pipe spacing or aluminum spreader plates.
Typically, 100–150mm spacing is recommended. Closer spacing increases responsiveness and comfort.
Use zone valves and programmable thermostats to independently control different areas of the home—this enhances comfort and energy savings.
A buffer tank can help maintain stable water temperature and reduce short cycling of the heat pump.
| Type | Considerations |
|---|---|
| New Build | Ideal scenario. Full design freedom, optimized insulation, and easy integration. |
| Retrofit | May require raising floor levels, improving insulation, or using ultra-thin UFH mats. Feasible with planning. |
Annual servicing of the heat pump
Periodic checks of underfloor manifold valves and actuators
Thermostat calibration to ensure optimal zone performance
System flushing every few years to remove potential sludge
Air to water heat pumps and underfloor heating systems are a highly compatible and energy-efficient combination for residential and commercial properties alike. Whether you're building a new home or retrofitting an old one, this modern heating solution offers long-term savings, better comfort, and a reduced environmental impact.
For optimal results, always work with experienced professionals who can design and install the system tailored to your property and heating needs.
