| Model | 50kW | 100kW | 210kW |
| GSHVTHP-50BA1 | GSHVTVP-100BA1 | GSHVTVP-210AA1 |
| Power Supply | 380~415V/3ph/50Hz |
| PV Max. Input Current(A) | 30 |
Optimal PV Input Voltage Range(V)
| 360~500 |
| Recommended PV Module Qty. (630W/50.2V)(pcs) | 2 strings * 11 modules | 4 strings * 11 modules | 4 strings * 11 modules |
| Nominal Heating (Max.) (A7/6, W30/35℃） |
| Heating Capacity(kW) | 46.0(13.9~52.8) | 92.0(28.5~107.8) | 176.0(49.7~213.0) |
| Power Input(kW) | 11.1(3.0~15.2) | 22.2(5.9~30.3) | 42.33(11.1~60.0) |
| COP | 4.14(3.50~4.75) | 4.15(3.52~4.80) | 4.16(3.55~4.82) |
Nominal Heating (Max.)(A7/6℃, W47/55℃)
|
| Heating Capacity(kW) | 43.3(13.5~49.5) | 86.5(27.9~102.3) | 172.0(48.6~202.0) |
| Power Input(kW) | 16.5(4.3~19.5) | 32.8(9.0~40.1) | 64.89(17.1~79.2) |
| COP | 2.63(2.53~3.12) | 2.64(2.53~3.12) | 2.65(2.55~3.12) |
Nominal Heating (Max.)(A-12/-14℃, W50/55℃)
|
| Heating Capacity(kW) | 34.0(10.3~35.3) | 68.0(21.3~72.1) | 136.8(36.3~141.0) |
| Power Input(kW) | 19.6(4.9~20.7) | 38.8(9.9~42.4) | 79.4(18.1~82.0) |
| COP | 1.73(1.70~2.20) | 1.75(1.70~2.20) | 1.72(1.65~2.15) |
| Nominal Cooling (Max.)(A35/24℃, W12/7℃) |
| Cooling Capacity(kW) | 28.0(12.2~30.6) | 56.0(25.2~62.5) | 106.0(39.4~135.2) |
| Power Input(kW) | 12.1(5.1~17.2) | 27.0(10.7~31.1) | 46.1(18.7~73.1) |
| General Data |
Max. Power Input(kW)
| 22.0 | 43.0 | 82.0 |
| Max. Current(A) | 43.5 | 85.0 | 160.0 |
| Compressor Quantity | 1 | 2 |
Expansion Valve
| EEV |
| Air Flow Direction | Vertical |
IP Class
| IPX4 |
| Water Flow Volume(m3/h) | 8.0 | 16.0 | 30.5 |
| Water Pressure Drop(kPa) | 70 | 73 | 76 |
| Working Temp. Range(℃) | -35~46 |
| Noise(dB(A)) | ≤65 | ≤68 | ≤76 |
| Water Connection(inch) | G1-1/2 | Flange DN65 | Flange DN80 |
| Net Weight(kg) | 450 | 780 | 1250 |
Dimensions(L*W*H)(mm)
| 1100*1100*2150 | 2200*1100*2250 | 2400*1160*2450 |
| Note: The data above is for reference only. Please refer to the nameplate on the unit if for more specific data. |
