| Model | 50kW | 75kW | 100kW |
| GSHVTH-050AA1 | GSHVTV-075AA1 | GSHVTV-100AA1 |
| Power Supply | 380~415V/3ph/50Hz |
| PV Max. Input Current(A) | 30 |
Optimal PV Input Voltage Range(V)
| 360~500 |
| Recommended PV Module Qty. (630W/50.2V)(pcs) | 2 strings * 11 modules | 4 strings * 11 modules | 4 strings * 11 modules |
| Nominal Heating (Max.) (A7/6, W30/35℃） |
| Heating Capacity(kW) | 18.50~50.50 | 25.00~76.00 | 35.50~105.00 |
| Power Input(kW) | 3.95~14.80 | 5.75~21.71 | 7.95~30.43 |
| COP | 3.50~4.70 | 3.55~4.65 | 3.50~4.62 |
Nominal Heating (Max.)(A7/6℃, W47/55℃)
|
| Heating Capacity(kW) | 10.85~40.00 | 19.58~67.27 | 26.85~93.45 |
| Power Input(kW) | 3.74~13.79 | 6.19~26.91 | 8.52~37.38 |
| COP | 3.02~3.52 | 2.50~3.38 | 2.55~3.28 |
| Nominal Cooling (Max.)(A35/24℃, W12/7℃) |
| Cooling Capacity(kW) | 10.15~28.50 | 13.50~48.50 | 16.20~65.50 |
| Power Input(kW) | 3.63~12.95 | 6.91~20.90 | 7.35~33.41 |
| EER | 2.20~2.70 | 2.00~2.45 | 2.00~2.50 |
| General Data |
Max. Power Input(kW)
| 19.3 | 30.5 | 40.5 |
| Max. Current(A) | 35.0 | 54.5 | 82.0 |
| ErP Level(35℃/55℃) | A+++/A++ |
| Max. Allowable Pressure(MPa) | 3.2 |
| Refrigerant | R290 |
| Electricall Shockproof | Ⅰ |
| Compressor Quantity | 1 | 2 |
| Fan Motor Quantity | 1 | 2 |
| Fan Motor Type | DC |
Expansion Valve
| EEV/Sanhua |
| Air Flow Direction | Vertical |
IP Class
| IPX4 |
| Water Flow Volume(m3/h) | 6.0 | 9.0 | 12.5 |
| Water Pressure Drop(kPa) | 65 | 75 | 76 |
| Working Temp. Range(℃) | -25~46 |
| Noise(dB(A)) | 55(39~55） | 62（54~72） |
| Water Connection(inch) | G1-1/2 | Flange DN80 |
| Net Weight(kg) | 450 | 780 | 900 |
Dimensions(L*W*H)(mm)
| 1100*1100*2150 | 2200*1100*2255 |
| Packed Dimensions(L*W*H)(mm) | 1144*1144*2250 | 2260*1160*2385 |
| Note: The data above is for reference only. Please refer to the nameplate on the unit if for more specific data. |
