| Modell |
6 kW |
8 kW |
10 kW |
10 kW |
12 kW |
12 kW |
14 kW |
14 kW |
16 kW |
16 kW |
18 kW |
18 kW |
24 kW |
30 kW |
34 kW |
| GSHVSH-6BA1 |
GSHVSH-8BA1 |
GSHVSH-10BA1 |
GSHVTH-10BA1 |
GSHVSH-12BA1 |
GSHVTH-12BA1 |
GSHVAH-14BA1 |
GSHVTH-14BA1 |
GSHVSH-16BA1 |
GSHVTH-16BA1 |
GSHVSH-18BA1 |
GSHVTH-18BA1 |
GSHVTH-24BA1 |
GSHVTH-30BA1 |
GSHVTH-34BA1 |
| Stromversorgung |
220~240V/1ph/50Hz |
220~240V/1ph/50Hz |
220~240V/1ph/50Hz |
380~415V/3ph/50Hz |
220~240V/1ph/50Hz |
380~415V/3ph/50Hz |
220~240V/1ph/50Hz |
380~415V/3ph/50Hz |
220~240V/1ph/50Hz |
380~415V/3ph/50Hz |
220~240V/1ph/50Hz |
380~415V/3ph/50Hz |
380~415V/3ph/50Hz |
380~415V/3ph/50Hz |
380~415V/3ph/50Hz |
| PV max. Eingangsstrom (A) |
18 |
18 |
18 |
18 |
30 |
18 |
30 |
18 |
30 |
18 |
30 |
18 |
30 |
30 |
30 |
| Optimaler PV-Eingangsspannungsbereich (V) |
180~350 |
180~350 |
180~350 |
360~500 |
180~350 |
360~500 |
180~350 |
360~500 |
180~350 |
360~500 |
180~350 |
360~500 |
360~500 |
360~500 |
360~500 |
Empfohlene PV-Modulmenge. (630W/50,2V)(Stück)
|
5 |
5 |
6 |
8 |
2 Strings * 4 Module |
8 |
2 Strings *5 Module |
10 |
2 Strings * 6 Module |
11 |
2 Strings * 6 Module |
11 |
2 Saiten * 9 Dokules |
2 Strings * 10 Module |
2 Strings * 11 Module |
| Nennheizung (max.) (A7/6℃, W30/35℃) |
| Heizleistung (kW) |
6,50 (2,80 ~ 8,80) |
8,20 (5,10 ~ 10,85)
|
10,05 (5,10 ~ 12,90) |
10,05 (5,10 ~ 12,90) |
12.00(5.90~15.12) |
12.00(5.90~15.12) |
14.05(6.10~16.99) |
14.05(6.10~16.99) |
15,80 (6,37–19,11) |
15,80 (6,37–19,11)
|
18.21(6.90~21.00) |
18.21(6.90~21.00) |
24.05(7.90~26.20) |
30.05(9.17~32.71) |
34,15 (9,17 ~ 36,80) |
| Leistungsaufnahme (kW) |
1,29 (0,59 ~ 1,95)
|
1,74 (0,86 ~ 2,42) |
2,16 (0,86 ~ 2,88) |
2,16 (0,86 ~ 2,88) |
2,45 (1,15 ~ 3,61) |
2,45 (1,15 ~ 3,61) |
2,99 (1,15 ~ 4,15) |
2,99 (1,15 ~ 4,15) |
3,43 (1,31 ~ 4,93)
|
3,43 (1,31 ~ 4,93) |
3,65 (1,36 ~ 5,28) |
3,65 (1,36 ~ 5,28) |
5,29 (1,78 ~ 6,45) |
6,60 (2,51 ~ 8,07) |
7,59(2,51(9,09) |
| COP |
4,70 (4,25 ~ 5,05) |
4,70 (4,23 ~ 5,08) |
4,65 (4,23 ~ 5,05) |
4,65 (4,23 ~ 5,05) |
4,90 (4,15 ~ 5,06) |
4,90 (4,15 ~ 5,06) |
4,70 (4,15 ~ 5,05) |
4,70 (4,15 ~ 5,05) |
4,64 (4,10 ~ 5,02) |
4,64 (4,10 ~ 5,02) |
4,99 (4,05 ~ 5,05) |
4,99 (4,05 ~ 5,05) |
4,55 (4,03 ~ 5,02) |
4,55 (4,05 ~ 5,03) |
4,50 (4,05 ~ 5,03) |
| Nennheizung (max.) (A7/6℃, W47/55℃) |
| Heizleistung |
5,88 (2,30 ~ 7,62) |
8,05 (3,85 ~ 9,41) |
9,50 (3,85 ~ 11,20) |
9,50 (3,85 ~ 11,20) |
12.00(4.90~13.15) |
12.00(4.90~13.15) |
13,98 (4,90 ~ 15,10) |
13,98 (4,90 ~ 15,10) |
15,70 (4,90 ~ 17,60) |
15,70(4,90~17,60 |
18.10(6.30~19.90) |
18.10(6.30~19.90) |
22,99 (6,90 ~ 26,10) |
29,86(9,73~31,82) |
33,50 (9,73 ~ 36,80) |
| Leistungsaufnahme |
1,78 (0,75 ~ 2,61) |
2,44 (1,13 ~ 3,15) |
2,92 (1,13 ~ 3,75） |
2,92 (1,13 ~ 3,75） |
3,96 (1,65 ~ 4,56) |
3,96 (1,65 ~ 4,56) |
4,30 (1,65 ~ 5,25) |
4,30 (1,65 ~ 5,25) |
4,83 (1,65 ~ 5,33) |
4,83 (1,65 ~ 5,33) |
5,82 (1,65 ~ 6,82) |
5,82 (1,65 ~ 6,82) |
8,04 (1,95 ~ 8,55) |
10,12 (2,75 ~ 10,36) |
11,55 (2,75 ~ 12,06) |
| COP |
3,30 (2,92 ~ 3,33) |
3,30 (2,99 ~ 3,46) |
3,25 (2,99 ~ 3,46) |
3,25 (2,99 ~ 3,46) |
3,03 (2,87 ~ 3,38) |
3,03 (2,87 ~ 3,38) |
3,25 (2,87 ~ 3,38) |
3,25 (2,87 ~ 3,38) |
3,25(2,87(3,38) |
3,25 (2,87 ~ 3,38) |
3,11 (2,91 ~ 3,34) |
3,11 (2,91 ~ 3,34) |
2,86 (3,05 ~ 3,42) |
2,95 (3,05 ~ 3,42) |
2,90 (3,05 ~ 3,42) |
| Nennkühlung (max.) (A35/24℃, W12/7℃) |
| Kühlleistung (kW) |
5,00 (1,80 ~ 7,10) |
7,00 (2,60–8,50) |
8,50 (2,60–10,30) |
8,50 (2,60–10,30) |
10,00 (4,50–11,85) |
10,00 (4,50–11,85) |
11,50 (4,50–13,50) |
11,50 (4,50–13,50) |
13.00 (5.05–15.00) |
13.00 (5.05–15.00) |
15,00 (5,50–17,50) |
15,00 (5,50–17,50) |
19,50 (5,20–21,30) |
23,50 (7,33 ~ 26,70) |
28,50(7,33~30,03) |
| Leistungsaufnahme (kW) |
2,00 (0,61 ~ 2,43) |
2,69 (0,91 ~ 2,93) |
3,40 (0,91 ~ 3,65) |
3,40 (0,91 ~ 3,65) |
4,00 (1,45–4,30) |
4,00 (1,45–4,30) |
4,42 (1,45 ~ 13,50) |
4,42 (1,45 ~ 4,85) |
5,20 (1,65 ~ 5,33) |
5,20 (1,65 ~ 5,33) |
6,00 (1,65 ~ 6,25) |
6,00 (1,65 ~ 6,25) |
7,80 (1,95 ~ 8,20) |
9,40 (2,75 ~ 10,27) |
11,40 (2,75 ~ 11,56) |
| EER |
2,50 (2,45 ~ 3,05) |
2,60 (2,45 ~ 3,05) |
2,50 (2,35 ~ 3,00) |
2,50 (2,35 ~ 3,00) |
2,50 (2,40 ~ 2,96) |
2,50 (2,40 ~ 2,96) |
2,60 (2,42 ~ 2,89) |
2,60 (2,42 ~ 2,89) |
2,50 (2,42 ~ 2,85) |
2,50 (2,42 ~ 2,85) |
2,50 (2,38 ~ 2,96) |
2,50 (2,38 ~ 2,96) |
2,50 (2,34 ~ 2,95) |
2,50 (2,36 ~ 2,98) |
2,50 (2,35 ~ 2,92) |
| Allgemeine Daten |
| ErP-Niveau (Auslasswassertemperatur bei 35℃/55℃) |
A+++/A++ |
| Nenneingangsleistung (kW) |
2.78 |
3.49 |
3.79 |
3.89 |
5.05 |
5.05 |
6.11 |
6.11 |
7.12 |
7.12 |
7.80 |
7.56 |
11.50 |
11.65 |
13.10 |
| Nenneingangsstrom (A) |
12 |
15 |
17 |
6.5 |
22.2 |
8.5 |
27.50 |
10.50 |
33.00 |
12.50 |
35.00 |
13.00 |
18.50 |
19.76 |
22.00 |
| Kältemittel |
R32 |
| Nennwasserdurchfluss (m³/h) |
1.1 |
1.38 |
1.72 |
1.72 |
2.06 |
2.06 |
2.41 |
2.41 |
2.75 |
2.75 |
3.10 |
3.10 |
4.12 |
5.85 |
5.85 |
| Druckabfall bei Nennwasserdurchfluss (kPa) |
29 |
32
|
35 |
39
|
| Lüftermenge |
1 |
2
|
| Lüftermotortyp |
DC-Wechselrichter |
| Kompressor |
DC-Wechselrichter/Rotary/EVI |
| Umwälzpumpe |
Wechselrichtertyp/Eingebaut |
| IP-Klasse |
IPX4 |
| Max. Auslasswassertemperatur (℃) |
60 |
| Betriebstemp. Bereich (Heizmodus) (℃) |
-38~43 |
| Betriebstemp. Bereich (Kühlmodus) (℃) |
16~48 |
| Schalldruck in 1 m Entfernung (dB(A)) |
49 |
43(39~52) |
45(39~52) |
45(39~52) |
54(39~53) |
45(39~53) |
46(39~53) |
46(39~53) |
48(39~54) |
48(39~54) |
48(39~54) |
48(39~54) |
52(40~58) |
52(42~62) |
52(42~62) |
| Wasserleitungsanschlüsse (Zoll) |
G1 |
G5/4
|
G3/2
|
| Nettogewicht (kg) |
113 |
120 |
120 |
121 |
128 |
126 |
132 |
131 |
132 |
131 |
175 |
174 |
181 |
212 |
212 |
| Bruttogewicht (kg) |
125 |
132 |
132 |
133 |
140 |
138 |
144 |
143 |
144 |
143 |
189 |
188 |
195 |
228 |
228 |
| Nettoabmessungen (L*T*H)(mm) |
1170*462*855 |
1130*452*1443
|
1220*452*1657
|
| Packmaße (L*T*H)(mm) |
1230*540*1010 |
1190*540*1600
|
1280*540*1815
|
